PRODUCT
Company Products

Product Introduction

JP
77S

Small Size of Automatic Poultry Cuntting Machine

Collaborative Robot with Operators

JP77S Alternate
With a variety of lineups Wide range of applications

Offering a variety of JP series lines to suit various environmental conditions.

  • Precision processing with 3D molds

    Utilizes 3D molds tailored to the size and weight of the chicken thighs. This enables precise unfolding of the chicken thighs for insertion, resulting in high processing accuracy.

  • Cube-shaped cutting function

    Equipped with a function to cut chicken thighs into cube shapes using a circular knife, allowing for the production of uniform and consistent-sized products.

  • Miniaturized JP77 model

    JP77S can be used for small workspaces by shrinking the JP77 model; optimizing these workspaces improves productivity.

    • Machine Specifications

    Product
    • Structure

      Stainless steel angle pipes, stainless steel bending structure

    • Operating Voltage

      3 -Phase 380V

    • Power Consumption

      3KW

    • HDPE Molds

      4EA

    Machine Size
    • Width

      3,050mm

    • Depth

      875mm

    • Height

      1,354mm

    KNIFE
    • Outer Diameter

      Ø 230

    • Inner Diameter

      Ø 32

    • Material

      440C

    • Thickness

      2mm

    Yield / Operator
    • Yield

      800 units / 1hr

    • Operator

      1 person
